Coaxial Cable 305m 75Ohm RG11 RG12 Communication System , China Coaxial Cable 305m 75Ohm RG11 RG12 Communication System Manufacturers, Suppliers, Factory

Coaxial cable 305m 75ohm rg11 rg12 communication system

Product Description

Description:

. Standard Mil-c-17

. Similar to: SYV75-4

. Insulation Material: Solid PE

. Impedance:75Ω±3

. Color: Black, White

Typical Application:RG11 RG12 is a specific type of coaxial cable, often used for transmission of a video and radio signals in application such as security system or CATV.

RG-11A/U SYV75-7 coaxial cable specifications
Material of Inner Conductor	Bare Copper, CCS
Structure of Inner Conductor	7/0.40mm
Material of Insulation	Solid PE
Diameter of Insulation	7.11mm
Material of Braiding(Shielding)	CCA, Bare Copper, Tinned Copper
Structure of Braiding(Shielding)	128*0.15mm
Material of Jacket	PVC
Diameter of Jacket	10.30mm
Working temp	-40℃/80℃
Impedance	75Ω±3
Voltage	4000V
